Bitumen Sprayer

AASPA We are a leading Manufacturer of bitumen sprayer, trolley mounted bitumen sprayer, truck mounted bitumen sprayer, bitumen pressure distributor and tractor mounted bitumen sprayer from Ahmedabad, India.

We would like to introduce ourselves of the Leading Manufacturer & Exporters of Road & Building Construction Machineries, based at Ahmedabad (India) Since Many Years ,Our Range of Products in Includes The following-

1) Concrete Batching Plant. (10 m3 to 120 m3 Capacity per Hour)

2) Mobile Concrete Batching Plant. (10 m3 to 30 m3 Capacity per Hour)

3) Wet Mix Plant. (WMM PLANT)(100 T.P.H to 250 T.P.H Capacities)

4) Asphalts Drum Mix Plants. (Hot Mix Plant) (20 T.P.H to 120 T.P.H Capacities)

5) Mobile Asphalts Drum Mix Plants. (Hot Mix Plant) (20 T.P.H to 60 T.P.H Capacities)

6) Asphalt Drum Mix Plant with Wet Mix Plant Duel Purposes. (Up to 90T.P.H Capacities)

7) Asphalts Tank 20Ton, 30Ton, 40Ton, and 50Ton capacity For Asphalts Plants.

8) 1, Ton 2.5 Ton & 3 Ton Capacities Bitumen Sprayer with Two Engines.

9) Reversible Drum type Mobile Concrete Batching Plant. (10m3 to 20m3 Capacities)

10) Mechanical & Hydraulic Broomer.

AASPA BITUMEN BOILER We are offering AE202  Bitumen Sprayer.
Features:

• Pressure cleaning system
• Easy operation
• Air cooled diesel engine

TANK

The tank is fabricated by a 5mm MS sheet and is coated with 40 mm glass wool. This is done to prevent heat loss. The outer covering is galvanized. Galvanized tank is better as it has long life due to its anti-corrosion properties Tank heating is the first stage. The heating pipeline of diameter e inches and the second stage is 6 inches. Manhole for maintenance or to all bitumen tank is if 500mm X 600mm. A manual Temperature gauge is provided for temperature display up to 300 Degrees Celsius.

ENGINE

Single stage air cooled diesel engineer of 6.5 HP at 1500 RPM, Engine powers bitumen pump and air compressor. Fuel consumption is 0.7-1 Liters per hour.

TANK

Tank is fabricated by a 5mm MS sheet and is coated by 40 mm glasswool. This is done to prevent heat loss. The outer covaring is galvanized. Galvanized tank is better as it has long life due to its anticorrosion properles Tank heeting is by a first stage. Heating pipeline of diameter e inches and scond stage is 6 inches. Manhole for maintenance or to all bitumen tank is if 500mm X 600mm. Manual Temperature guage is provided for temperature display upto 300 Degrees celcius.

BURNER

Single high pressure oil burner for adequate heating of viscose binder with oil consumtion of 7-8 Liters/hrs. Burner comatible with Diesel.

ENGINE

Single stage air cooled diasel enginer of 6.5 HP at 1500 RPM, Engine powers bitumen pump and air compressor. Fuel consumption is 0.7-1 Liters per hour.

BITUMEN PUMP AND AIR COMPRESSOR

Both bitumen pumps and air compressor are engine dilven. Bitumen pump is connected to the engine by a manual clutch. Just ongaging the clutch will activate the pump. Bitumen pump gear type 200 to 300 Liters per minute. 2 HP Single piston air compressor is provided.

AASPA BITUMEN BOILER We are offering AE202  Bitumen Sprayer.
Features:

• Pressure cleaning system
• Easy operation
• Air cooled diesel engine

TANK

The tank is fabricated by a 5mm MS sheet
